305mm Mitre Saw
DWS780-GB
305mm Mitre Saw
- Available in: India
- Cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly adjust angles between 0° - 50° left and 0° - 60° right
- Compact and lightweight design characteristics deliver a saw with enormous capacity which is easy to transport around the jobsite
Product Overview
The 305mm Mitre Saw is engineered for repeatable accuracy with dual horizontal rails and a stainless steel detent plate with common angles at 0, 15, 22.5, 31.6, 35.3 and 45 degrees, the 1675 watt motor also offers a maximum cutting capacity of 305 x 77mm. Other features include XPS crosscut positioning system for the ultimate in accuracy and visibility with no calibration needed and machined side handles for increased portability on site.
Additional Features
- XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity no adjustment required
- New quick release bevel stop setting provides accurate and simple setting of bevel angles up to 49° left and right
- The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications
- Linear horizontal rails utilise bronze guides to provide maximum precision when cutting materials up to 345 mm wide
- Outstanding dust control and deflection away from cutting area
- The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles
- 1100 Watt motor designed for heavy duty applications
- 4 position blade clamp allows for flush cutting and increased versatility
- With a 29 mm stroke length, the DWE305PK delivers excellent cutting performance
- Lever-action keyless blade clamp for quick and easy blade changing
- Ideal for plumbers, electricians, heating, HVAC , and builders"
Includes
- (1) Dust bag
- (1) Blade spanner
- (1) High quality 60 tooth blade
- (1) Material clamp
Specifications
|
Blade Bore [Metric]
|
30 mm
|
|
Blade Speed
|
1900-3800 rpm
|
|
Max. Cutting Capacity (45°/45°) [Metric]
|
211 x 63 mm
|
|
Max. Depth of Cut [Metric]
|
170 mm
|
|
Saw Blade Thickness [Metric]
|
2.6 mm
|
|
Possible Mitre Angles
|
50°/60°
|
|
Max. Cutting Capacity (90°/90°) [Metric]
|
303 x 110 mm
|
|
Bevel Capacity
|
49/49°
|
|
Product Width [Metric]
|
470 mm
|
|
No Load Speed (RPM)
|
1900-3800
|
|
Max. Cutting Capacity (45°/90°) [Metric]
|
211 x 112 mm
|
|
Product Height [Metric]
|
396 mm
|
|
Product Weight [Metric]
|
25.5 Kg
|
|
Blade Diameter [Metric]
|
305 mm
|
|
Supplied in Storage Case Indicator
|
No
|
|
Uncertainty K1 (Vibration)
|
1.5 m/s2
|
|
Max. Cutting Capacity (90°/45°) [Metric]
|
268 x 63 mm
|
|
Power Source
|
Corded
|
|
Power Input
|
1675 W
|
|
Packaging
|
Carton
|
|
Product Length [Metric]
|
770 mm
|
